2024 Ford F-150® Lightning near Mentor, OH
The 2024 Ford F-150® Lightning represents a technically advanced approach to all-electric truck design, configured for function, performance, and precision. Built with a high-strength steel frame and a military-grade aluminum alloy body, this model is engineered for utility and durability. The SuperCrew® body style accommodates five passengers. Final assembly is completed at the Rouge Electric Vehicle Center, underscoring its alignment with Ford’s electric manufacturing standards.
Payload and Towing Configurations
Payload capacity varies depending on battery selection and trim. Vehicles equipped with the Standard-Range battery achieve a maximum payload of 2,235 pounds. The Extended-Range battery supports a payload of up to 1,913 pounds. Towing capacity also scales with configuration. The base towing figure is 5,000 pounds for Standard-Range variants and 7,700 pounds for Extended-Range models. Maximum towing increases to 10,000 pounds when equipped with the Max Trailer Tow Package on Flash and Lariat® trims. Platinum models max out at 8,500 pounds with the same package. Payload and towing ratings are calculated independently and are subject to variations based on installed equipment and total vehicle load.
Battery System and Charging Capabilities
Energy is stored using a lithium-ion pouch cell system with integrated liquid cooling and internal battery management. The Standard-Range battery provides 98 kWh of usable energy. The Extended-Range battery increases this to 131 kWh. Input/output ratings for onboard charging vary. The Standard-Range battery system supports 11.3 kW input with 10.5 kW output at 48A. The Extended-Range version, limited to fleet use, supports 19.2 kW input and 17.6 kW output at 80A. Assembly of the battery units is handled at the Rawsonville Components Plant using a similar sourcing strategy.
Charging times differ depending on equipment. A 150 kW or higher DC fast charger can bring the battery from 15 to 80 percent in approximately 32 minutes for the Standard Range and 38 minutes for the Extended-Range. A Level 2, 48A connected charge station requires 10 to 13 hours for a full charge. The 30A 240V mobile charger extends this time to 15 to 20 hours. Using a DC fast charger for 10 minutes adds approximately 62 miles of range with the Standard-Range battery and 65 miles with the Extended-Range. The maximum EPA-estimated driving range is 320 miles with the Extended-Range battery on the Flash and Lariat® trims. Platinum models are rated at 300 miles, and Standard-Range variants reach 240 miles under optimal conditions.
Disclaimer: Range and charge time based on manufacturer computer engineering simulations, tested values, and EPA-estimated range calculation methodology. The charging rate decreases as battery reaches full capacity. Your results may vary based on peak charging times and battery state of charge. Actual range varies with conditions such as external environment, vehicle use, vehicle maintenance, high-voltage battery age, and state of health.
Structural Dimensions and Physical Layout
The vehicle is structured around a 145.5-inch wheelbase. Its overall length measures 232.7 inches, while cab height reaches 78.3 inches. The body spans 80 inches in width, excluding mirrors, and 96 inches with mirrors extended. Folded, the mirror width is 83.6 inches. Ground clearance is set at 8.5 inches. Angles of approach and departure are 24.3 and 24.0 degrees, respectively. The ramp breakover angle is 17.6 degrees. The rear overhang measures 49.4 inches. The front trunk liftover height is 34.5 inches, and the open tailgate extends to a height of 37.1 inches from ground level.
Interior space allows for five occupants. Front headroom is 40.8 inches, legroom is 43.9 inches, and shoulder room reaches 66.7 inches. Rear passengers receive 40.4 inches of headroom, 43.6 inches of legroom, and 66.0 inches of shoulder room. Cargo bed volume is 52.8 cubic feet, while the front trunk or “frunk” provides an additional 14.1 cubic feet.
Dual-Motor Configuration and Power Ratings
The 2024 Ford F-150® Lightning is equipped with two inboard fixed-magnet three-phase AC motors. These are mounted transversely at the front and rear to deliver a standard four-wheel-drive layout. Two performance configurations are available. The version with the Standard-Range battery is rated at 452 horsepower. The extended-range battery version increases power output to 580 horsepower. Torque output is identical for both options at 775 lb-ft, providing uniform traction performance across configurations. Both motors are assembled domestically at the Van Dyke Transmission Plant using a combination of domestic and international components.
Suspension and Chassis Systems
The front suspension consists of an independent double-wishbone layout combined with coil-over shocks and a stabilizer bar. Heavy-duty gas-pressurized monotube shocks are standard. The rear suspension includes independent semi-trailing arms, a stabilizer bar, coil springs, and gas-pressurized twin-tube shocks. These suspension components work in tandem with the battery placement to maintain balance and vehicle control.
Integrated Software and Digital Features
The 2024 Ford F-150® Lightning is configured with SYNC® infotainment systems depending on trim. Lower trims feature SYNC® 4 with a 12-inch landscape touchscreen. Lariat® and Platinum trims upgrade to SYNC® 4A, offering a 15.5-inch vertical touchscreen. Apple CarPlay® and Android Auto™ integration is standard. A 12-inch digital productivity screen is also included across all models for monitoring vehicle functions.
Software updates are delivered over the air to maintain system performance. Each trim includes FordPass® Connect with Wi-Fi hotspot capability for up to 10 devices. Navigation services with a three-year trial are available through connected systems. Select trims support “Phone As A Key” functionality, allowing smartphone-based vehicle access. A 360-degree camera system is available on all but the base trim. Enhanced voice recognition and intelligent access are standard on Lariat® and higher.
Lighting, Exterior Features, and Body Equipment
Exterior lighting includes LED projector headlamps with dynamic bending and LED signature lighting across all trims. LED taillamps are also standard. The signature front light bar and tailgate lighting become standard beginning with the Flash trim. LED box lighting with Enhanced Zone Lighting is included on the Lariat® and above trims.
Body options include power up/down hoods on all trims. Tailgates vary, with lift-assist standard on entry models and power operation standard on Lariat® and Platinum. Running boards range from fixed Carbon Black units on lower trims to power deployable units on Platinum. Wheel sizes vary from 18 to 22 inches, with optional matte black finishes and black lug nut configurations.
Driver Assistance and Safety Technology
All trims include Ford Co-Pilot360™ 2.0. This includes Pre-Collision Assist® with Automatic Emergency Braking, Pedestrian Detection, Forward Collision Warning, and Dynamic Brake Support. Blind Spot Information System with Trailer Coverage, Lane-Keeping System, Reverse Sensing System, Post-Collision Braking, and Auto High Beam headlamps are also standard.
Upper trims include Ford Co-Pilot360™ Assist 2.0. This package provides Intelligent Adaptive Cruise Control with Stop-and-Go, Lane Centering, Speed Sign Recognition, Intersection Assist, and Evasive Steering Assist. The vehicle also offers Ford BlueCruise® hands-free driving capability for highway operation, provided through either a 90-day trial or a three-year plan based on trim.
Additional standard systems include AdvanceTrac® with Roll Stability Control™, Curve Control, and the SOS Post-Crash Alert System. A perimeter anti-theft alarm and a tire pressure monitoring system are also included.
Interior Equipment and Material Options
Trim-dependent seating options range from vinyl to premium leather. Pro trim models include heated front bucket seats with manual adjustments. Flash and Lariat® provide 10-way power-adjustable heated and ventilated seats with power lumbar support. The Platinum trim includes Nirvana leather seating surfaces with tuxedo striping. All trims feature a flow-through console with a stowable floor shifter. Rain-sensing wipers, memory driver’s seat functions, and interior work surfaces are included on upper trims.
Onboard Power Systems and Trailer Features
The vehicle features integrated power delivery systems through Pro Power Onboard™. A 2.4kW version is standard on most trims, distributing 120V power through outlets in the cab, bed, and front trunk. An available 9.6kW system expands outlet counts and introduces a 240V outlet in the bed. Tow-focused packages offer Trailer Reverse Guidance, Smart Hitch, and On-board Scales. The Max Trailer Tow Package includes a Trailer Brake Controller and is available on all trims.
Visit Nick Mayer Ford East to Schedule a Test Drive
To evaluate the functional design, power delivery, and integrated systems of the 2024 Ford F-150® Lightning, scheduling a test drive provides direct insight. Key performance indicators such as motor output, towing capacity, and digital connectivity can be reviewed during the drive. For those interested in exploring these systems in person, test drives are available at Nick Mayer Ford East near Mentor, OH. This enables potential operators to assess the model’s full electric platform under actual conditions.
